Description
The S-25-6M0 slickline wire has a very good resistance for general corrosion. It can work very well in well with H2S and CO2, excellent in in corrosive environments (chloride, brine or salts) and corrosive elements. The equivalent type would be SUPA75 .
| C | Si | Mn | P | S | Cr | Ni | Mo | Co | N | Cu | W | Fe | |
| Percentage | <0.02 | <0.5 | <2.0 | <0.030 | <0.008 | 19.0-21.0 | 24.0-26.0 | 6.00-7.00 | – | 0.15-0.25 | 0.5-1.5 | – | balance |
| OD | Weight | PREN | Breaking Strength | |||
| in | mm | lb/kft | kg/km | lbs | Kn | |
| 0.092 | 2.33 | 23 | 34 | 47 | 1551 | 6.90 |
| 0.108 | 2.74 | 32 | 48 | 47 | 2170 | 9.65 |
| 0.125 | 3.18 | 43 | 64 | 47 | 2850 | 12.68 |
| 0.140 | 3.56 | 54 | 80 | 47 | 3400 | 15.12 |
| 0.160 | 4.06 | 70 | 104 | 47 | 4400 | 19.57 |
Any outer diameter and length can be customized, the whole slickline wire of Φ4.0mm can be reached to 13000+ meters.
Can recommend slickline type selection based on the user’s target well conditions (temperature, pressure, H2S, CO2, chloride concentration, etc.)
All slickline wire products are sampled at both ends for bending, stretching, torsion and wraping tests before leaving the factory.
From the purchase and processing of raw materials until the product delivery to user, we adopt quality control measures such as continuous monitoring /recording / measurement to ensure that the product is free from any defects.
Self-owned testing center has the ability of chemical composition analysis, metallographic analysis,
mechanical property testing, scanning electron microscope analysis and energy spectrum analysis.
Guarantee that the delivered slickline wire is free of weld spots and pass the Eddy Current Test.
